HAVOC Tool V4
HAVOC Tool V4
First, you'll have to order your own battery and gps antenna from amazon and a 32/64 gb microsd for it have its full potential. It doesn't come with them sadly, you'll need to use a usb-c cable at first.
(https://www.amazon.com/dp/B07MD9C1ZL?psc=1&ref=ppx_yo2ov_dt_b_product_details,
https://www.amazon.com/dp/B0BS1RNZGM?psc=1&ref=ppx_yo2ov_dt_b_product_details, https://www.amazon.com/PNY-Elite-microSDHC-Memory-P-SDU32GU185GW-GE/dp/B07R8GVGN9/ref=sr_1_4?keywords=32gb%2Bmicrosd&sr=8-4&th=1).
Why does my screen appear to be used/ have scratches?
The screen will also appear to have scratches but it's just the screen protector. All you have to do is carefully remove the back and unscrew the board from the case and peel off the protective film. "BE SLOW, don't just rip it off then undo the two screws and slowly and gently pull it out "
What is the Havoc tool useful for?
Also, The havoc tool is really only practical for wifi pen testing along with Bluetooth pen testing and locating access points, and stations connected to those access points. There is a cool feature that Bluetooth spams for IOS that can crash devices and There’s other stuff to like deauthing networks, capturing pcaps, etc.
Why is the GPS not working even with an antenna?
It needs time to find a fix and it finds it best when it’s outside but you also need to get an antenna of your choice for the antenna too. So he didn’t make the antenna on board but rather with a ufl connector so you can connect any size gps antenna These antennas will fit in the case but you can go as crazy as you want as long as it connects via UFL. You could even hypothetically use a car antenna
Why isn't my network coming up?
The Htool only works on 2.4ghz networks because "5ghz has legal issues"
What are the dimensions?
About 3.5in x 2in and 1 inch thick (edited)
Diginex AKZYTUE 3.7V 500mAh 602535 Lipo Battery Rechargeable Lithiu...
Warning: 1.Before use, please check the battery voltage, positive and negative polarity with the original battery, the opposite will lead to equipment damage. The red wire is the positive pole "+", the black wire is the negative pole "-". In some products, the original battery does not have a plu...
Dual Band Antenna, 2Pcs GPS BD Antenna Ceramic Active Dual Band Hig...
Specification: Item Type: GPS BDAntenna Model: GPS TC 005 Material: Ceramic Working Frequency: 1561Mhz 1575.42Mhz Antenna Gain: 28DBI Impedance: 50Ω Working Temperature: -40℃~+85℃ Interface Model: IPEX Head Line Type: RG1.13 Line Standing Wave Ratio: ≤1.5 Polarization Method: Vertical Polarizati...
PNY 32GB Elite Class 10 U1 microSDHC Flash Memory Card - 100MB/s re...
PNY Elite class 10 U1 microSD flash memory cards are perfect for the latest smartphones tablets action cameras surveillance cameras and drones These microSD cards Perfect solution by which to expand on-board memory of mobile devices allowing you to free up space to enjoy more digital content such...
[11:15 AM]
How can I put my own programs on the device?
You flash it via arduino IDE or via esphuhn webtool he has a video on it on his Tiktok
Why isn't the GPS UFL connector going in?
Press into it until you feel a little click or it’s not moving, this will take some force
Will everything fit in the case?
yes, just shift and shimmy things around until everything fits nice and snug in the case but be careful not to break anything (photo below)
What is wardriving?
Wardriving is to ping internets and stations via gps locations
Does the Htool have esp32Marauder pre-intalled?
Yes.
software: https://github.com/justcallmekoko/ESP32Marauder
Why isn't it working when I click stuff, like in the EAPOL sniffer?
"click the inverse of where the button is. The firmware has some bugs that need fixing"
How do I "recover" my wifi password
You need to capture .pcaps With a selected station Then use hash cat or wire shark to crap the pcap files
He has a tutorial on it on his Tiktok "Donanontech"
Donanontech is very helpful if you need help with anything else feel free to contact him at donanontech on discord.
HAVOC Tool V4
pictures below
First, you'll have to order your own battery and gps antenna from amazon and a 32/64 gb microsd for it have its full potential. It doesn't come with them sadly, you'll need to use a usb-c cable at first. (picture below)
(https://www.amazon.com/dp/B07MD9C1ZL?psc=1&ref=ppx_yo2ov_dt_b_product_details, https://www.amazon.com/dp/B0BS1RNZGM?psc=1&ref=ppx_yo2ov_dt_b_product_details, https://www.amazon.com/PNY-Elite-microSDHC-Memory-P-SDU32GU185GW-GE/dp/B07R8GVGN9/ref=sr_1_4?keywords=32gb%2Bmicrosd&sr=8-4&th=1).
Why does my screen appear to be used/ have scratches?
The screen will also appear to have scratches but it's just the screen protector. All you have to do is carefully remove the back and unscrew the board from the case and peel off the protective film. "BE SLOW, don't just rip it off then undo the two screws and slowly and gently pull it out "
What is the Havoc tool useful for?
Also, The havoc tool is really only practical for wifi pen testing along with Bluetooth pen testing and locating access points, and stations connected to those access points. There is a cool feature that Bluetooth spams for IOS that can crash devices and There’s other stuff to like deauthing networks, capturing pcaps, etc.
Why is the GPS not working even with an antenna?
It needs time to find a fix and it finds it best when it’s outside but you also need to get an antenna of your choice for the antenna too. So he didn’t make the antenna on board but rather with a ufl connector so you can connect any size gps antenna These antennas will fit in the case but you can go as crazy as you want as long as it connects via UFL. You could even hypothetically use a car antenna
Why isn't my network coming up?
The Htool only works on 2.4ghz networks because "5ghz has legal issues"
What are the dimensions?
About 3.5in x 2in and 1 inch thick
How can I put my own programs on the device?
You flash it via arduino IDE or via esphuhn webtool he has a video on it on his Tiktok
Why isn't the GPS UFL connector going in?
Press into it until you feel a little click or it’s not moving, this will take some force
Will everything fit in the case?
yes, just shift and shimmy things around until everything fits nice and snug in the case but be careful not to break anything (photo below)
What is wardriving?
Wardriving is to ping internets and stations via gps locations
Does the Htool have esp32Marauder pre-intalled?
Yes.
Why isn't it working when I click stuff, like in the EAPOL sniffer?
"click the inverse of where the button is. The firmware has some bugs that need fixing"
How do I "recover" my wifi password
You need to capture .pcaps With a selected station Then use hash cat or wire shark to crap the pcap files
He has a tutorial on it on his Tiktok "Donanontech"
Donanontech is very helpful if you need help with anything else feel free to contact him at donanontech on discord.
This tool has been a joy to handle and mess around with and was an awesome gift from my brother! I have quite a few other devices like the flipper zero and this one definitely has its own unique fun things about it. the form factor is perfect and great to take around with me on the go, and has all the features marauder can run including wardriving with GPS. Definitely recommend this seller and device as it continues to get better :)
A few issues, the clips that hold the back on quickly snapped, the reset button falls out on the floor, it has trouble recognising the micro SD card and there is no instructions on the correct format. The touchscreen came with scratches on it. Other than that Functionally it’s a great device
Hello,
Sorry to hear about some of the short comings with the first runs of the device. Firstly i did mention in a few videos to be very careful when opening the device as to not break the back off the device due to it being a screwless external design.
As for the SD card i have also mentioned along with just call me koko that very specific Micro SD cards are necessary to be used and need to be within a certain memory range (16gb to 32gb is most successful) that also have to be in FAT32.
Also in case you didn't happen to notice the screen doesn't come with scratches, there is a protective film on the screen that you can peel off if you choose to that the parts come with themselves.
if you have any questions reach out an i can totally help you! :)
